Hunter Signature Luxe 3 Horse (12t)
The HUNTER SIGNATURE LUXE 3 HORSE is the mid size model in the Hunter Range. No expense has been spared with its beautiful spacious layout. A large 3 horse truck with rear facing angle bays, still a very easy horsebox to use even when traveling alone.
This model comes to life in the separate living area, it’s like having your very own 5-star hotel on board. Some of the features included full separate bathroom with generous shower, toilet and porcelain sink. Large Pop out in the lounge increases the space and offers the third bed, along side the Luton king single and double sky bed above the Bathroom. As for cooking there is a twin induction hob, large domestic sink and combination microwave and large domestic 113ltr fridge. There are beautifully upholstered seats in your choice of colours and many interior options to choose from.
This model offers a massive 4,000kg of payload for 3 large horses. Off grid accommodation is brought to life by the 6kwt Inverter Yamaha generator with built in touch start operation making staying away as comfortable as possible.
Chassis
DAF, Iveco Eurocargo or MAN Auto transmission
- GVM: 12,000kg
- Tare: 8,000kg
- Payload: 4,000kg*
- Twin rear wheels (single axle)
- Rear wheel drive
- 3.5t towing capacity**
*Payload dependent on additional upgrades, fixtures & fittings
** Towing capacity based on Australian tow bar upgrade/electric brakes (additional cost)
Horse Area
32mm insulated composite roof panel- Aluminium plank flooring (for entire floor from cab to ramp)
- 12mm single-piece nylon reinforced sealed rubber floor
- 2 x drain holes
- 3 element side panels (insulated – composite fibre glass & aluminium skin with 22mm EVA rubber walls)
- Concealed internal steel box construction to perimeter walls for added strength
- Internal jockey door to horse area from living area
- Full dividing wall between horse and living area 11mm GRP panel with reinforced concealed box steel internals
- 2.44m Internal head height (horse area)
- 2 horse bays 2.5m long x 0.96m wide (adjustable rear angle load)
- 3 x air vents over horses rumps
- Dual colour camera system (Horse area & reversing camera)
- 2 windows (Horse heads)
- 2 windows at horse rump (both sides)
- 2 x Electric cooling roof fan with cab digital readout & remote control
- 6 x internal tie rings
- 4 x external tie rings
- 1 x white LED ramp loading light
- 2 x Internal LED lights in horse bays
- Hydraulic ramp loading system
- 2 x calming travel light in horse area
- External hot/cold horse shower pack
- Raised living floor with full truck width 2.2m underbody storage for hay and feed
- Large double door underbody tack locker with 3 x swing out saddle poles & bridle hooks
- 3 x drivers side mounted external lockers/storage compartments
- 1 x passengers side mounted external bridle locker
- Rear mud/stone guard (full width of horsebox)
- Marker lights
- Recessed led docking lights for reversing visibility
Living Area
Create 3m² of living space behind the drivers cab by utilising the lounge slide out- 2 permanently set up double beds (Luton above cab and Sky bed above bathroom)
- Stow-away dining table
- Couch converts to double bed
- Side living area external door access with window, blind, and drop-down stairs
- 4 x opening tinted windows with flyscreens and blinds
- LED lighting, including downlights & floor mood lighting
- Kardean wood flooring in a choice of colours
- High-quality wood effect panelling with padded roof lining
- Wardrobe with door and integrated hanging rail
- Multiple mirrors throughout
- Separate bathroom with shower, toilet & porcelain sink, heated towel rail, and cupboard storage
- Galley style kitchen with induction cooktop
- Sink with tap and drainer
- 240v Microwave
- 12v/240v 130l fridge/freezer
- Hot water system, connections & 175l under-body water tank
- Multiple storage cabinets & lockers, including under-seat storage
- 5G Wi-Fi system
- 24inch 12v Smart TV in living area and 24inch 12v Smart TV in skybed
- Pop-up 240v power points with USB and wireless charging
- Double 12v leisure battery & power management system
- 240v electric hook-up
- Internal digital switch control panel
- External mains water system hook-up (to hosepipe)
- Premium reverse cycle air-conditioning
- Solar Panels and power management system
Downloads
Virtual Tour
3yrs/200,000km Iveco
Professional Warranty*
*3 years or 200,000kms, whichever comes first
(warranties are valid for personal and business use only
but excludes horse transport companies (such use of vehicles
will void any warranty claims))
1yr/50,000km Horsebox
Body Warranty*
*1yr or 50,000kms, whichever comes first
(warranties are valid for personal and business use only
but excludes horse transport companies (such use of
vehicles will void any warranty claims))
